12+0.6+0.6µm Carbon Coated Aluminum Foil

12+0.6+0.6µm Carbon Coated Aluminum Foil is a composite foil fabricated by depositing a conductive carbon layer on the surface of electronic aluminum foil substrate, primarily used as a positive current collector in lithium-ion batteries. By reducing contact resistance, enhancing adhesion of active materials, and preventing oxidation and corrosion of the aluminum foil, it significantly improves battery cycle life, safety, and cell consistency.

Inquiry Now

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

12+0.6+0.6µm Carbon Coated Aluminum Foil, Featuring a medium-thickness substrate with standard double-sided carbon coating, it offers a balanced combination of mechanical strength, low interfacial impedance, corrosion resistance, and excellent roll-pressing performance (no coating delamination). It is primarily suited for lithium iron phosphate (LFP) batteries and targets customers requiring high-rate capability and long cycle life. It also serves select high-loading NMC, energy storage, and specialty capacitor manufacturers.

Applicable battery	Lithium ion battery / Sodium ion battery
Alloy	AA1100, AA1060, AA1235D
Temper	H18
Aluminum Foil Thickness	8-15µm
Coating Thickness	0.6-2µm (single side/double sides)
Aluminum Foil Width	300-1550mm
Coating System	Aqueous slurry
Surface tension	≥64 dyn/cm
Total Surface density	33.5-41.5±1 g/㎡
Coating surface density	0.21-0.7±0.5 g/㎡
NMP resistance	Baked at 130 °C for 10 min. Wiping 200 times with NMP, coating remains intact without peeling
